    High Resolution Wall Mounted Kiosk , Custom Self Service Check In Kiosk

    Ask Lasest Price
    Brand Name : HUAYIN
    Model Number : HY-WM010
    Certification : CE, FCC, ROHS, ISO, EMV, PCI
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 5000 UNITS/M
    Delivery Time : 4-5 WEEKS
    • Product Details
    • Company Profile

    High Resolution Wall Mounted Kiosk , Custom Self Service Check In Kiosk

    Wall Mounted Self-service Check In Kiosk with Touch Screen and Bill Payment Functions​


    Introduce:

    This kiosk is mounted on wall, can save room and queuing time, enhance user experience and efficiency.

    This wall mounted kiosk model comes with elegant curves and rugged enclosure. Users can arrange self payment through this machine, and payment can be done by credit/debit cards, a receipt will be printed upon request.


    Function:


    Support wireless access and LAN access

    • Accurate touch screen and simple operation
    • Support multi-lingual GUIs and volume regulation
    • Support payment by banknote
    • Support IC cards, magnetic stripe cards and RFID cards
    • Support RFID card reader and barcode scanner
    • Support 80mm thermal printing (with paper auto-cutting)
    • Support card dispenser
    • High-definition facial photographing
    • Support Windows/Linux operating system
    • Automatic startup/shutdown
    • Self-diagnosis alarming
    • Support management via PMS (payment management system)

    Features:

    • Rich business applications
    • Customizable color, appearance, peripheral equipments and more
    • Modular design for convenient operation and maintenance
    • Real-time transmission of encrypted data
    • Robust anti-vandalism design
    • User-friendly GUIs

    Application:

    • Airtime top-up
    • Prepaid card sales (e.g. Wi-Fi account cards, game cards and VoIP calling cards)
    • Bill payment (e.g. water, electricity and gas, etc.)
    • E-ticket (e.g. barbershop tickets, meal tickets and movie tickets)
    • Card payment and top-up
    • Self-service card dispensing (e.g. meal cards, credit cards, SIM cards and gift cards )
    • Hotel check-in
    • Other extended services

      High Resolution Wall Mounted Kiosk , Custom Self Service Check In Kiosk


      Specification:


      Specification:

      Network accessWCDMA

      Dual-Band UMTS/HSDPA 850/2100 MHz or

      Dual-Band UMTS/HSDPA 900/2100 MHz

      LAN100/1000 Mbps
      Industrial PCCPUIntel dual-core CPU, 1.8GHz or above
      RAM2G or above
      Hard disk500G HD/32G SATA HD
      Other configuration6interfaces, 6 USB ports, 1 Ethernet interface, video card, audio card, support TCP/IP protocol
      ScreenTouch screen17’’ / 19’’, 4096*4096 pixels
      LCD17’’ / 19’’, 32-bit true color, 1280*1024 pixels
      Card reader moduleMagnetic stripe card standardISO7810, ISO7811
      IC card standardISO7816
      RFID card standardISO14443 (Type A/B)
      Frequency13.56 MHz
      CertificationEMV
      CoinIdentification capacity15 denominations
      Identification rate>98%
      Coin size

      Diameter: 16 mm~31 mm

      Thickness: 1.2 mm~3.2 mm

      Coin box type and capacityClosed box, 2L
      Open box, 2L~4L (optional)
      BanknoteIdentification rate>95%
      Insertion direction4 directions
      Banknote box type and capacityClosed box, 300/600/1000 pcs
      Card dispenser moduleCapacity120/200/500 pcs
      Barcode scannerBarcode type1D/2D
      Scanning speed104 times/s
      Printer modulePrinter typeThermal printer
      Printing width58/80 mm
      Lifespan50 km
      Maximum printing speed200 mm/s
      Password keypadKey quantity16 pcs
      Key materialStainless steel
      CertificationPCI
      Power supplyInputAC 100V~240V, 50 Hz~60 Hz
      UPSInputAC 220±10%, 60/50 Hz, 500 VA
      Operating environmentTemperature0°C~+ 55°C
      Humidity10%~95%
      StructureCasing materialPowder-coated SECC
